EMU-2it AC/DC current analyzer with universal current input
AC/DC current analyzer with universal current input
| Introduction |
| Range |
EMU |
| Product name |
EMU-2it |
| Product type |
Power meter |
| Technical characteristics |
| Applications |
Current AC/DC monitoring |
| Type of measurement |
True RMS
Current
Crest factor
Frequency
Total current harmonic distortion THD (I)
|
| Supply voltage |
10...30 VDC |
| Network frequency |
40 Hz
70 Hz |
| Rated current [In] |
5 A
1 A
10 mV - 1V con CT +/- 1 Vpk
100 mV - 10V con CT +/- 10 Vpk
1 mA - 100 mA con CT 20/100 mA
Sensori di HALL +/-15 VDC |
| Power consumption |
2 VA |
| Sampling |
6400 samples/s 50 Hz |
| Accuracy class |
Current +/- 0.5 % |
| Communication port |
RS485 |
| Communication protocol |
Modbus 4,8...115,2 kbauds |
| Number of temperature inputs |
1 (PT100 o NTC) |
| Number of analog outputs |
1 |
| Mounting mode |
DIN rail 1 module |
| Standards |
EN61000-6-3
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61010-1 |
| Weight |
55g |
| Environment |
| IP degree of protection |
IP20 |
| Relative humidity |
10...90% |
| Operating temperature |
-10...+60 °C |
| Storage temperature |
-20...+85 °C |
| Options |
| Power quality analysis |
Up to the 63rd harmonic
Total current harmonic distortion THD (I) |
